Note: Special Handling Fees ApplyThis Warn Series 9 hydraulic winch has 9,000 lb. of pulling power. Hardened steel and two-stage planetary gear trains deliver efficient and reliable operation plus fast line speeds. Warn winches are designed for Heavy-Duty Towing and Recovery Operations. They comply with world-wide quality and safety standards. This specific model comes with the 4.9 cu. in clockwise motor and has a pulling force rating of 9,000 lbs., due to the hydraulic motor sizing. Clockwise, 4.9 cu in motor Rated pulling force: 9000 lbs. (4082 kg) Drum barrel diameter: 4.00 in (102 mm) Drum flange diameter: 8.24 in (209 mm) Distance between flanges: 9.95 in (253 mm) Recommended maximum wire rope diameter: 1/2 in (12.7 mm) Recommended minimum wire rope breaking strength: 15,100 lbs. (6849 kg) Approximate shipping weight: 98.0 lbs. (44.5 kg) Perfect for towing, utility and trailer applications Heavy Duty automatic disc brake provides dependable operation Meets SAE J706 CE standards Wire rope, roller fairlead, and tensioner sold separately Gear reduction: 27:1 Hardened steel, two-stage planetary geartrain provides faster line speeds 4.9gpm, Clockwise drum rotation Limited Lifetime Warranty for Mechanical Components Limited Five (5) Year Warranty for Electrical Components Specifications Type: Hydraulic Mount Type: Vehicle Mounted Recommended Use: Industrial Voltage: Not Applicable Motor Horsepower: Not Applicable Electrical Control Type: Not Applicable Thermal Shutoff: No Drive Gear Type: Planetary Gear Reduction Ratio: 27:1 Free Spooling: Yes Brake Type: Disc Brake Line Diameter (in): No Rope Line Length (ft): No Rope Line Material: No Rope Fairlead Type: No Fairlead Conforms To J706 Standards: Yes Mounting Hole Quantity: 8 Operation Type: Automatic Mounting Pattern Length (in): 12 Inch Mounting Pattern Width (in): 4-1/2 Inch Includes Mounting Hardware: No Color: Black Max Line Pull/Line Speed: 9000 Pound/28.5 Feet Per Minute Applications Towing & Recovery Utility Trailer
